W-Band Balanced Upconverter

75 to 110 GHz, DC to 35 GHz IF, +13 dBm LO Power, WR-10 Waveguide
SKU:SFU-10-N1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SFU-10-N1 is a W-Band balanced upconverter that utilizes high performance GaAs Schottky beam-lead diodes and a balanced circuit configuration to offer superior RF performance. The upconverter supports the full waveguide band operation for both LO and RF frequencies from 75 to 110 GHz with an extremely broad IF output from DC to 35 GHz. The upconverter offers a conversion loss of 13 dB typical and a high RF to LO port isolation of 30 dB.
ECCN: 3A001.b.7.b.1
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$3,000.00
3 - 4$2,850.00
5 - 9$2,707.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum RF Frequency75 GHz
Maximum RF Frequency110 GHz
Minimum LO Frequency75 GHz
Maximum LO Frequency110 GHz
Minimum IF FrequencyDC
Maximum IF Frequency35 GHz
LO Pumping Power+13 dBm
Conversion Loss9.5 dB
RF PortWR-10 Waveguide
