W-Band Compact Level Setting Attenuator

75 to 110 GHz, 0 to 30 dB, WR-10 Waveguide
SKU:STA-30-10-M1-C-1.2
STA-30-10-M1-C-1.2 is a WR-10 compact level setting attenuator that covers the frequency range from 75 to 110 GHz. The attenuator features a high resolution precision micrometer which allows for finer adjustment sensitivity than a standard micrometer. The level setting attenuator is an ideal piece of equipment in waveguide systems where broadband level setting is required. The attenuator exhibits 0.3 dB typical insertion loss and up to 30 dB nominal attenuation value across the entire operating bandwidth. The other attenuator types, such as direct reading, programmable and fixed tuned attenuators are also available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency75 GHz
Maximum Frequency110 GHz
Attenuation0 to 30 dB
Return Loss20 dB
Power Handling0.1 W
RF PortWR-10 Waveguide
Attenuator TypeLevel Setting
ConfigurationCompact
