W-Band Receiver

75 to 110 GHz, 14 dB Noise Figure, 30 dB Gain
SKU:SSK-SC753114-10-S0
Availability:Contact Us for Quote
Select up to 4 products to compare.
Select up to 4 products to compare.
SSK-SC753114-10-S0 is a W-Band receiver. The receiver has a typical conversion gain of 30 dB with a typical RF input power of -60 dBm in the frequency range of 75 to 110 GHz and a IF output frequency range of 10 MHz to 3 GHz. The required LO power and frequency range are +2 dBm and 12.5 to 18.33 GHz, respectively . The LO and IF port are both equipped with female SMA connectors and the RF port is a WR-10 waveguide with a UG-387/U-M flange.
ECCN: 3A002.e
Login to view pricing

Technical Details

RF Input Frequency75 to 110 GHz
RF Input Power-60 dBm
Noise Figure14 dB
IF Output Frequency10 MHz to 3 GHz
RF to IF Conversion Gain30 dB
LO Frequency12.5 to 18.33 GHz
LO Input Power+2 dBm
LO DC Bias Voltage+12 VDC/760 mA
RF PortWR-10 Waveguide
RX IF Port and LO PortSMA (F)
