E-Band Receiver

71 to 86 GHz, DC to 4 GHz IF, 20 dB Harmonic Suppression, 0 dBm LO Power
SKU:SSR-7930830010-12-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SSR-7930830010-12-S1 is an E-Band receiver. The receiver has a typical conversion loss of 10 dB with a typical RF input power of -20 dBm in the frequency range of 71 to 86 GHz and an IF output frequency range of DC to 4 GHz. The receiver has a build in X8 multiplier, which requires the input LO power and frequency range of 0 dBm and 8.875 to 10.75 GHz, respectively. The LO and IF port are both equipped with female SMA connectors and the RF port is a WR-12 waveguide with a UG-387/U flange.
ECCN: 3A002.e
Login to view pricing

Technical Details

Minimum RF Frequency71 GHz
Maximum RF Frequency86 GHz
Noise Figure12 dB
Gain-10 dB
LO Frequency9.8 GHz
LO Input Power0 dBm
Bias Voltage12 VDC
RF PortWR-12 Waveguide
