E-Band Receiver

71 to 86 GHz, DC to 12 GHz IF, 20 dB Harmonic Suppression, +10 dBm LO Power
SKU:SSR-7930837005-12-S1
Availability:4 to 6 Weeks ARO
SSR-7930837005-12-S1 is an E-Band receiver. The receiver has a typical noise figure of 7.0 dB and conversion gain of 4 dB with a RF linear input power of -15 dBm in the frequency range of 71 to 86 GHz and an IF output frequency range of DC to 12 GHz. The required LO power and frequency range are +10 dBm and 8.875 to 10.75 GHz, respectively. The LO and IF port are both equipped with female SMA connectors and the RF port is a WR-12 waveguide with a UG-387/U flange.
ECCN: EAR99
To view pricing or check order status

Technical Details

RF Input Minimum Frequency71 GHz
RF Input Maximum Frequency86 GHz
Conversion Gain4 dB
LO Frequency9.8 GHz
LO Input Power10 dBm
Bias Voltage12 VDC
RF PortWR-12 Waveguide
