4-Way In-line Power Divider

71 to 86 GHz, 15 dB Port Isolation, WR-12 Waveguide, E-Band
SKU:SWP-71386304-12-E1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWP-71386304-12-E1 is an E band, 4-way power divider with a typical insertion loss of 0.8 dB across the frequency range of 71 to 86 GHz. The divider offers 25 dB isolation and well-balanced ports, which can be used for in-phase power dividing or combining. This power divider comes as an in-line configuration with WR-12 waveguides and UG-387/U Anti-cocking flanges at the input and all outputs.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,300.00
5 - 9 $1,170.00
10 - 24 $1,053.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency71 GHz
Maximum Frequency86 GHz
Insertion Loss0.8 dB
Port Isolation15 dB
Amplitude Imbalance±0.4 dB
Port VSWR1.2
Power Division4 Way
ConfigurationIn-line (180°)
Input/Output PortsWR-12 WG
