V-Band Wide Mechanical Tuning-Bandwidth Gunn Oscillator

67 GHz, ±8 GHz Tuning Bandwidth, +7 dBm Output Power, WR-15 Waveguide
SKU:SOF-1507-M1
Availability:6 to 8 Weeks ARO
SOF-1507-M1 is a V-Band, wide mechanical tuning bandwidth Gunn oscillator that utilizes a high-performance GaAs Gunn diode and proprietary cavity design to deliver +7 dBm typical power with low AM/FM noise and harmonic emissions. The oscillator has a center frequency of 67 GHz and a mechanical tuning range of ±8 GHz. Compared to its multiplier-based counterparts, the Gunn oscillator is a lower cost alternative and a cleaner source. The Gunn oscillator is equipped with a micrometer for quick frequency tuning when used as a bench top unit. Models with a self-locking set screw for frequency tuning are available under a different model number for use in system integration applications. The performance of the oscillator can be further enhanced by adding an optional integrated isolator, Gunn oscillator modulator/regulator, and temperature heater.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 1$6,150.00
2 - 2$5,842.50
3 +$5,550.38

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Center Frequency67 GHz
Output Power+7 dBm
Mechanical Tuning Range±8 GHz
Bias+4.5 VDC/1 A
RF PortWR-15 Waveguide
