E-Band Compact Level Setting Attenuator

60 to 90 GHz, 0 to 30 dB, WR-12 Waveguide
SKU:STA-30-12-M1-C-1.2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STA-30-12-M1-C-1.2 is a WR-12 compact level setting attenuator that covers the frequency range from 60 to 90 GHz. The attenuator features a high resolution precision micrometer which allows for finer adjustment sensitivity than a standard micrometer. The level setting attenuator is an ideal piece of equipment in waveguide systems where broadband level setting is required. The attenuator exhibits 0.3 dB typical insertion loss and up to 30 dB nominal attenuation value across the entire operating bandwidth. The other attenuator types, such as direct reading, programmable and fixed tuned attenuators are also available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency60 GHz
Maximum Frequency90 GHz
Attenuation0 to 30 dB
Return Loss20 dB
Power Handling0.1 W
RF PortWR-12 Waveguide
Attenuator TypeLevel Setting
ConfigurationCompact
