E-Band Low Noise Amplifier

60 to 90 GHz, 25 dB Gain, 5.0 dB Noise Figure, In-line WR-12 Waveguide
SKU:SBL-6039032550-1212-E1
Availability:1 Week ARO
SBL-6039032550-1212-E1 is a low noise amplifier with a typical small signal gain of 25 dB and a nominal noise figure of 5 dB across the frequency range of 60 to 90 GHz. The DC power requirement for the amplifier is +8 VDC/30 mA. The mechanical configuration offers an in line structure with WR-12 waveguides and UG-387/U anti-cocking flanges. Other port configurations, such as with 1 mm connectors or a right angle structure with WR-12 waveguides, are also available under different model numbers.
ECCN: 3A001.b.4.e.3
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$3,100.00
3 - 4$2,945.00
5 - 9$2,797.75

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency60 GHz
Maximum Frequency90 GHz
Gain25 dB
Noise Figure5.0 dB
P1dB+3 dBm
Input Return Loss8 dB
Output Return Loss8 dB
DC Bias+8 VDC/30 mA
RF Input/OutputWR-12 Waveguide
