WR-12 Waveguide Shim

60 to 90 GHz, 0.077" (L) Insertion Length, 77 Mils, 3/8 λg
SKU:SWI-12077-SB
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWI-12077-SB is a 0.077" thick, 3/8 wavelength, instrumentation grade E Band waveguide spacer (shim) with WR-12 window and UG-387/U circular flange. The spacer is manufactured with a precision machining process to ensure high quality and ruggedness. The spacer is offered to cover the frequency range of 60 to 90 GHz.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 24$165.00
25 - 49$148.50
50 +$133.65

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency60 GHz
Maximum Frequency90 GHz
Insertion Length0.077" (L)
Mils77
WaveguideWR-12 Waveguide
