X4 Active Frequency Multiplier

SFA-553903416-12KF-E1 is an active X4 frequency multiplier. The multiplier has an input frequency of 13.75 GHz to 22.5 GHz with a typical input power of +3 dBm and an output frequency of 55 to 90 GHz with a typical output power of +16 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/600 mA. The input port configuration is a female 2.92 mm connector and the output is a WR-12 waveguide with a UG-387/U anti-cocking flange. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
