V-Band Orthomode Transducer

50 to 75 GHz, 40 dB Isolation, 35 dB Cross Polarization, 0.148" x 0.148" Square Waveguide Antenna Port
SKU:SAT-FV-14815-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAT-FV-14815-S1 is a full band, WR-15 orthomode transducer (OMT) operating between 50 and 75 GHz. The OMT separates a circular or elliptical polarized waveform into two linear, orthogonal waveforms or combines two linear polarized waveforms into one circular or elliptical polarized waveform or vice versa. The OMT also supports either vertical or horizontal polarized waveguide forms with more than 30 dB cross polarization rejections. The OMT is configured with a 0.148" x 0.148" square waveguide for the antenna port and two WR-15 waveguides for the horizontal and vertical ports. All ports have UG-385/U anti-cocking flanges with 4-40 threaded holes.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$2,150.00
5 - 9$1,935.00
10 +$1,741.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Insertion Loss, Antenna to V Port0.6 dB
Insertion Loss, Antenna to H Port1.0 dB
Isolation40 dB
Cross Polarization35 dB
Antenna Port0.148" x 0.148" Square WG
Horizontal and Vertical PortsWR-15 WG
