2 Way Right Angle Power Divider

50 to 75 GHz, 20 dB Port Isolation, WR-15 Waveguide, V-Band
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWP-50375302-15-S1 is a WR-15, 2-way power divider that operates from 50 to 75 GHz. The power divider offers a typical insertion loss of 0.5 dB across the frequency range of 50 to 75 GHz. The power divider offers 20 dB isolation and well-balanced ports, which can be used for in-phase power dividing or combining. This model comes as a right-angle configuration with WR-15 waveguides and UG-385/U anti-cocking flanges at the input and outputs ports.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 9 $850.00
10 - 24 $765.00
25 - 49 $688.50

Bulk Availability

1 In Stock

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Insertion Loss0.5 dB
Port Isolation20 dB
Power Unbalance±0.3 dB
Input/Output Return Loss20 dB
Power Division2 Way
ConfigurationRight Angle (90°)
Input/Output PortsWR-15 WG
