V-Band Noise Source with Faraday Isolator

50 to 75 GHz, 13 dB ENR, WR-15 Waveguide
STZ-15-IT2 is a V-Band noise source that delivers 13 dB ENR with extreme flatness across the frequency range of 50 to 75 GHz. The noise source is integrated with Eravant miniature faraday isolator to improve the port VSWR and load pull for more reliable and accurate noise figure measurements. The noise source can work in either CW or pulse AM mode by applying a TTL triggering signal via a female SMA connector. This feature can also be used in automatic test systems to remotely turn the noise source on and off. In addition, a toggle switch (power/triggering inversion switch) is provided to turn the noise source on and off manually.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
ENR13 dB
ENR Flatness±1.5 dB
AM Modulation Rate1 kHz
Return Loss15 dB
DC Bias+28VDC/30mA
RF OutputWR-15 Waveguide
