V-Band Phase Shifter

50 to 75 GHz, 0 to 180° Range, WR-15 Waveguide
Availability:4 to 6 Weeks ARO
STP-18-15-M1 is a V-Band micrometer driven phase shifter that covers the frequency range of 50 to 75 GHz. The phase shifter features a precision micrometer dial with a knurled head locking screw, which allows for stable, repeatable settings that can be locked at any phase shift value. The phase shifter is an ideal piece of equipment in waveguide systems where broadband phase shifting is required. The phase shifter exhibits a 0.8 dB typical insertion loss and an adjustable phase range of up to 180 degrees.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 9 $790.00
10 - 24 $711.00
25 - 49 $639.90

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Insertion Loss0.8 dB
Phase Shifting Range0 to 180°
Power Handling600 mW (CW)
Input/OutputWR-15 Waveguide
