2-Way Coaxial Power Splitter

5 to 65 GHz, 1.85 mm (F)
SKU:SCS-0536533816-VFVF-27
Availability:4 to 6 Weeks ARO
SCS-0536533816-VFVF-27 is a coaxial 2-way power splitter with a typical insertion loss of 3.8 dB at each output port and a typical isolation of 16 dB across the frequency range of 5 to 65 GHz. The power splitter has a power handling of 5 W (CW) and a typical amplitude unbalance of ±0.6 dB. The return loss for all ports is 11 dB typical. The RF connectors of the power splitter are female 1.85 mm (V) female connectors.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $1,220.00
5 - 9 $1,098.00
10 - 24 $988.20

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency5 GHz
Maximum Frequency65 GHz
Ways2
Insertion Loss3.8 dB
Port Isolation16 dB
Return Loss11 dB
Impedance50 Ohms
RF ConnectorsV (F)
