X4 Active Frequency Multiplier

45 to 70 GHz, +20 dBm Output Power, In-line WR-15 Waveguide, V-Band
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SFA-453703420-15SF-E1 is an active X4 frequency multiplier. The multiplier has an input frequency of 11.25 to 17.50 GHz with a typical input power of +5 dBm and an output frequency of 45 to 70 GHz. The typical output power is +20 dBm. The multiplier also has a typical harmonic suppression of -20 dBc. The DC power requirement for the multiplier is +8 VDC/1000 mA. The input port configuration is a female SMA connector and the output is a WR-15 waveguide with a UG-385/U anti-cocking flange. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: 3A001.b.7.b.2
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency45 GHz
Maximum Output Frequency70 GHz
Output Power+20 dBm
Minimum Input Frequency11.25 GHz
Maximum Input Frequency17.50 GHz
Input Power+5 dBm
DC Bias+8 VDC/1000 mA
Output PortWR-15 Waveguide
Input PortSMA (F)
