X4 Active Frequency Multiplier

45 to 70 GHz, +13 dBm Output Power, In-line WR-15 Waveguide, V-Band
SKU:SFA-453703413-15SF-E1
Availability:1 Week ARO
SFA-453703413-15SF-E1 is an active X4 frequency multiplier. The multiplier has an input frequency of 11.25 to 17.50 GHz with a typical input power of +5 dBm and an output frequency of 45 to 70 GHz. The typical output power is +13 dBm. The multiplier also has a typical harmonic suppression of -20 dBc. The DC power requirement for the multiplier is +8 VDC/600 mA. The input port configuration is a female SMA connector and the output is a WR-15 waveguide with a UG-385/U anti-cocking flange. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Quantity Price
1 $5,650.00
2 $5,367.50
3 - 4 $5,099.13

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency45 GHz
Maximum Output Frequency70 GHz
Output Power+13 dBm
Minimum Input Frequency11.25 GHz
Maximum Input Frequency17.50 GHz
Input Power+5 dBm
DC Bias+8 VDC/600 mA
Output PortWR-15 WG
Input PortSMA (F)
