X4 Active Frequency Multiplier

SFA-403703413-VFSF-S1 is an active X4 frequency multiplier. The multiplier has an input frequency of 10 to 17.5 GHz with a minimum input power of 0 dBm and an output frequency of 40 to 70 GHz with a typical output power of +13 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/800 mA The input port configuration is a female SMA connector and the output is a female 1.85 mm connector. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
