U-Band Low Noise Amplifier with Uni-Guide™

40 to 60 GHz, 25 dB Gain, 4.0 dB Noise Figure, In-line WR-19 Waveguide
SKU:SBL-4036032540-1919-E1
Availability:3 to 5 Days ARO
SBL-4036032540-1919-E1 is a low noise amplifier with a typical small signal gain of 25 dB across the frequency range of 40 to 60 GHz and a nominal noise figure of 4.0 dB. The DC power requirement for the amplifier is +8 VDC/60 mA. The mechanical configuration offers an in-line structure WR-19 Uni-Guide™ waveguides. Other port configurations, such as a right angle structure with WR-19 waveguides or 1.85 mm connectors, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency40 GHz
Maximum Frequency60 GHz
Gain25 dB
Noise Figure4.0 dB
P1dB0 dBm
Input Return Loss8 dB
Output Return Loss10 dB
DC BiasSolder Pin
RF Input/OutputWR-19 Uni-Guide™ Waveguide
