X2 Active Frequency Multiplier

40 to 60 GHz, +15 dBm Output Power, 2.92 mm (F) Input, 1.85 mm (M) Output
SKU:SFA-403603215-VMKF-S1
Availability:4 to 6 Weeks ARO
SFA-403603215-VMKF-S1 is an active X2 frequency multiplier. The multiplier has an input frequency of 20 to 30 GHz with a typical input power of +5 dBm and an output frequency of 40 to 60 GHz with a typical output power of +15 dBm. The multiplier also has a typical harmonic suppression of -20 dBc. The DC power requirement for the multiplier is +8 VDC/400 mA. The input port configuration is a female K 2.92 mm connector and the output is male V 1.85 mm connector. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $3,650.00
3 - 4 $3,467.50
5 - 9 $3,294.13

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency40 GHz
Maximum Output Frequency60 GHz
Output Power+15 dBm
Minimum Input Frequency20 GHz
Maximum Input Frequency30 GHz
Input Power+5 dBm
DC Bias+8 VDC/400 mA
Output PortV (M)
Input PortK (F)
