SMA Coaxial Bandpass Filter

4 to 12 GHz, 25 dB Rejection from 12.5 to 50 GHz
SKU:SCF-08308320-SFSF-B1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCF-08308320-SFSF-B1 is a coaxial bandpass filter to pass the frequency of 4 to 12 GHz. The maximum insertion loss of the bandpass filter is 2.0 dB and passband ripple is ±0.5 dB. The rejection frequencies are 3.5 GHz or less and 12.5 GHz or higher and the minimum rejection is 20 dB. The RF connectors of the the filter are SMA (F) connectors. The passband VSWR of the filter is 2:1 maximum.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 9 $910.00
10 - 24 $819.00
25 - 49 $737.10

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband Frequency4 GHz
Maximum Passband Frequency12 GHz
Low Side Rejection25 dB
High Side Rejection25 dB
Return Loss10 dB
Insertion Loss1.5 dB
Impedance50 Ohms
RF PortsSMA (F)
