W-Band Lens Corrected Antenna

36 dBi Gain, 71 to 86 GHz, WR-10 Waveguide
SKU:SAL-7138633602-10-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAL-7138633602-10-S1 is a lens corrected antenna that operates from 71 to 86 GHz. At a center frequency of 78.5 GHz, the antenna delivers 36 dBi nominal gain and a typical half-power beamwidth of 2 degrees E-plane and 3 degrees on the H-plane. The antenna employs a low loss lens to offer excellent aperture efficiency and low side lobe levels. The lens corrected antenna is equipped with a WR-10 waveguide with a UG-387/U-M as its input port. It supports linear polarized waveforms.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency71 GHz
Maximum Frequency86 GHz
Gain36 dBi
3 dB Beamwidth (E-plane, H-plane)2°, 3°
Return Loss20 dB
PolarizationLinear
Antenna PortWR-10 Waveguide
