E-Band Lens Corrected Antenna

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-WR12GAIN-06D.
A 2D pattern measurement test is offered under service number FTA-WR12PATT-06D.

CLICK HERE to read more about our antenna measurement capabilities.

SAL-7138633602-125-S1 is a lens corrected antenna that operates from 71 to 86 GHz. At the frequency of 78.5 GHz, the antenna delivers 36 dBi nominal gain, and a typical half-power beamwidth of 2 degrees E-plane and 3 degrees on the H-plane. The antenna employs a low loss lens to offer excellent aperture efficiency and low sidelobe levels. The lens corrected antenna is equipped with a 0.125" diameter circular waveguide as its input port. It supports both linear and circular polarized waveforms. The model with WR-12 waveguide is offered under model number SAL-7138633602-12-S1.
