Q-Band Power Amplifier with Uni-Guide™, Limited Run

35 to 47 GHz, 35 dB Gain, +20 dBm P1dB, 2.4 mm (F), WR-22 Waveguide
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider SBP-3335033020-2F22-E1 as an alternative solution. Read more about Limited Run Products here.

SBP-3534733520-2F22-E1 is a power amplifier with a typical small signal gain of 35 dB and a nominal P1dB of +20 dBm across the frequency range of 35 to 47 GHz. The DC power requirement for the amplifier is +8 to +12 VDC/1,000 mA. The mechanical configuration offers an inline structure with a 2.4 mm (F) connector as its input port and a WR-22 Uni-Guide™ waveguide and UG-383/U flange as its output port. Other port configurations, such as an in line or right angle structures with WR-22 waveguides or 2.4 mm connectors, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency35 GHz
Maximum Frequency47 GHz
Gain35 dB
P1dB+20 dBm
Psat+22 dBm
Input Return Loss15 dB
Output Return Loss6 dB
DC Voltage+8 VDC
DC Bias1000 mA
RF Input/Output2.4 mm (F) Connector/WR-22 Uni-Guide™ Waveguide
