Ka-Band Volume Production Oscillator

35 GHz, ±2.00 GHz Tuning Bandwidth, +17 dBm Output Power, WR-28 Waveguide
SKU:SOL-35317-28-G1-3
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SOL-35317-28-G1-3 is a volume-production ready, Ka Band Gunn oscillator that utilizes a high performance GaAs Gunn diode and high Q cavity to achieve excellent phase noise and power stability. The oscillator is designed for fixed frequency applications, however, the frequency can be adjusted by ±2.0 GHz using the self-locking set screw provided.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,050.00
5 - 9$945.00
10 - 24$850.50

Bulk Pricing

Login to View Pricing

Technical Details

Center Frequency35 GHz
Output Power+17 dBm
Mechanical Tuning Range±2000 MHz
Varactor Tuning Range-
Phase Noise-95 dBc/Hz @ 100 KHz offset
Bias+5.5 VDC/650 mA
Varactor Tuning Voltage Range-
RF PortWR-28 Waveguide
