Ka-Band Dual Channel, Long Range Ranging Sensor Heads

35 GHz,+10 dBm Transmitting Power, 29 dBi Antenna Gain
Availability:2 Weeks ARO
SSD-35310-29L-D1 is a Ka Band, lens antenna-based ranging sensor head that is designed and manufactured for long range measurements of a moving or stationary target's range, speed and direction. The sensor head has a center frequency of 35 GHz and takes a nominal bias of +5.0 VDC/250 mA. The frequency modulation bandwidth of ±75 MHz minimum is realized via a tuning voltage of 0 to +20 Volts. The sensor heads are configured with a lens corrected antenna, T/R diplexer, a dual channel (I/Q) receiver and a transmitter/receiver oscillator in an integrated package. Sensor heads with a single receiver are offered under model number SSD-35310-29L-S1 and can only detect the range and speed of a target.
Login to View Pricing

Bulk Pricing

1 - 4$1,600.00
5 - 9$1,440.00
10 - 24$1,296.00

Bulk Pricing

Login to View Pricing

Technical Details

RF Center Frequency35 GHz
TX Power+10 dBm
Antenna Gain29 dBi
3 dB BW (H x V)5° x 5°
PolarizationRH Circular
DC Bias+5 VDC/250 mA
