Ka-Band Volume Production Varactor Tuned Gunn Oscillator

35 GHz, ±0.15 GHz Varactor Tuning Bandwidth, +7 dBm Output Power, WR-28 Waveguide
SKU:SOL-35307-28-GV
Availability:1 Week ARO
SOL-35307-28-GV is a volume-production ready, Ka Band Varactor tuned Gunn oscillator that utilizes high performance GaAs Gunn and Varactor diodes, optimized in the high Q cavity, to achieve excellent phase noise and power stability. The oscillator delivers +7 dBm output power at 35 GHz with an electrical tuning bandwidth of ±150 MHz. The center frequency of the oscillator can be mechanically trimmed by using the self-locking set screw provided. The oscillator takes +5.5 VDC/250 mA DC power.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,050.00
5 - 9$945.00
10 - 24$850.50

Bulk Pricing

Login to View Pricing

Technical Details

Center Frequency35 GHz
Output Power+7 dBm
Mechanical Tuning Range±1 GHz
Varactor Tuning Range±150 MHz
Phase Noise-90 dBc/Hz @ 100 KHz offset
Bias+5.5 VDC/250 mA
Varactor Tuning Voltage Range0 to +24 Volts
RF PortWR-28 Waveguide
