SMA Coaxial Bandpass Filter

35.4 to 35.6 GHz, 70 dB Rejection
SKU:SCF-36302270-SFSF-B3
Availability:6 to 8 Weeks ARO
SCF-36302270-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 35.4 to 35.6 GHz. The typical insertion loss of the bandpass filter is 4 dB and the passband ripple is ±0.3 dB. The rejection frequencies are 34.8 GHz or less and 36.3 GHz or higher. The typical rejection is 70 dB and the typical passband return loss of the filter is 14 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,450.00
5 - 9$1,305.00
10 +$1,174.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Passband Frequency35.4 GHz
Maximum Passband Frequency35.6 GHz
Low Side Rejection70 dB
High Side Rejection70 dB
Return Loss14 dB
Insertion Loss4 dB
Impedance50 Ohms
RF PortsSMA (F)
