Ka-Band Power Amplifier with Uni-Guide™

34 to 37 GHz, 45 dB Gain, +37 dBm Psat, 2.92 mm (F), WR-28 Waveguide
SKU:SBP-3433734535-KF28-E3
Availability:4 to 6 Weeks ARO
SBP-3433734535-KF28-E3 is a power amplifier with a typical small signal gain of 45 dB and a nominal P1dB of +35 dBm across the frequency range of 34 to 37 GHz. The DC power requirement for the amplifier is +28 VDC/5 A. The RF input is a 2.92 mm female connector and the output is a WR-28 Uni-Guide™ waveguide. Other port configurations, such as male 2.92 mm connectors for either the input or output port, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 $9,950.00
2 $9,452.50
3 - 4 $8,979.88

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency34 GHz
Maximum Frequency37 GHz
Gain45 dB
P1dB+35 dBm
Psat+37 dBm
Input Return Loss9 dB
Output Return Loss9 dB
DC Bias+28 VDC/5 A
RF Input/Output2.92 mm (F) Connector/WR-28 Uni-Guide™ Waveguide
