Q-Band Orthomode Transducer

33 to 50 GHz, 40 dB Isolation, 35 dB Cross Polarization, 0.224" x 0.224" Square Waveguide Antenna Port
SKU:SAT-FQ-22422-S1
Availability:1 Week ARO
SAT-FQ-22422-S1 is a WR-22 orthomode transducer (OMT) that operates between 33 and 50 GHz. The OMT separates a circular or elliptical polarized waveform into two linear, orthogonal waveforms or combines two linear polarized waveforms into one circular or elliptical polarized waveform. The OMT shows high port isolation and high cross-polarization cancellation while providing a low insertion loss. The OMT is configured with a 0.224" x 0.224" square waveguide for the antenna port and two WR-22 waveguides for the horizontal and vertical ports. All ports have standard UG-383/U-M flanges.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,950.00
5 - 9$1,755.00
10 +$1,579.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency50 GHz
Insertion Loss, Antenna to V Port0.8 dB
Insertion Loss, Antenna to H Port0.8 dB
Isolation40 dB
Cross Polarization35 dB
Antenna Port0.224" x 0.224" Square WG
Horizontal and Vertical PortsWR-22 WG
