Q-Band Compact Fixed Attenuator

33 to 50 GHz, 3 dB, 2.0" Insertion Length, WR-22 Waveguide, Non-Standard UG-599 Square Flange
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STA-03-22-F1-C-599-2.0 is a compact fixed attenuator with an insertion length of 2.0”. The attenuator is used in millimeterwave systems and operates from 33 to 50 GHz. The attenuator has a fixed attenuation value of 3 dB at the center frequency, 41.5 GHz. While the attenuator is designed and fabricated for full waveguide band applications, the attenuation value of this model does show a minor slope within the band due to its distinct mechanical configuration. Other attenuation values are available under different model numbers as STA-XX-22-F1-C-599-2.0, where XX is the desired attenuation value.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency50 GHz
Attenuation3 dB @ 41.5 GHz
Return Loss20 dB
Power Handling1 W
RF PortWR-22 Waveguide
Attenuator TypeFixed
