Ka-Band Low Noise Amplifier with Uni-Guide™

33 to 37 GHz, 30 dB Gain, 3.0 dB Noise Figure, WR-28 Waveguide, 2.92 mm (F)
SKU:SBL-3333733030-28KF-E1
Availability:1 to 2 Weeks ARO
SBL-3333733030-28KF-E1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 3 dB across the frequency range of 33 to 37 GHz. The DC power requirement for the amplifier is +8 VDC/150 mA. The mechanical configuration is an inline structure with a WR-28 Uni-Guide™ waveguide as its input port and K(F) connector as its output port. Other port configurations, such as K connectors and WR-28 waveguides for either the input or output port, are also available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,750.00
5 - 9$1,575.00
10 +$1,417.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency37 GHz
Gain30 dB
Noise Figure3.0 dB
P1dB+10 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/150 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide/2.92 mm (F) Connector
