Ka-Band Lens Corrected Antenna

30 dBi Gain, 25 to 27 GHz, WR-28 Waveguide
SKU:SAL-2532733005-28-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAL-2532733005-28-S1 is a lens corrected antenna that operates from 25 to 27 GHz. At the frequency of 26 GHz, the antenna delivers 30 dBi nominal gain, 4.5 degrees E-plane, and 5.5 degrees H-plane half power beamwidth, respectively. The antenna employs a low loss lens to offer excellent aperture efficiency and low sidelobe levels. The lens corrected antenna is equipped with a WR-28 waveguide and UG-599/U compatible flange as its input port. It supports linear polarized waveforms.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency25 GHz
Maximum Frequency27 GHz
Gain30 dBi
3 dB Beamwidth (E-plane, H-plane)4.5°, 5.5°
Return Loss-20 dB
PolarizationLinear
Antenna PortWR-28 Waveguide
