Ka-Band Omnidirectional Antenna

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-ODA.
A 2D pattern measurement test is offered under service number FTA-0400PATT-ODA.

CLICK HERE to read more about our antenna measurement capabilities.

SAO-2434030345-KF-E1 is a full band, Ka band omnidirectional antenna that covers the frequency range of 24 and 40 GHz. This vertically polarized antenna offers 360 degrees azimuth coverage with a 3 dBi typical gain and ±1 dB nominal gain flatness. The antenna features a half power beamwidth of 45 degrees in its vertical direction. The RF port of the antenna is equipped with K(F) coaxial connector. The version with a right-angle K(F) connector is offered under model number, SAO-2434030345-KF-R1.
