Coaxial Fixed Attenuator

3 dB Attenuation, 2.4 mm (M) to (F), DC to 50 GHz, 2 Watt
SKU:SCA-03-2M2F-S9
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCA-03-2M2F-S9 is a 3 dB coaxial attenuator that is used in millimeterwave systems and operates from DC to 50 GHz. The attenuator has a typical attenuation value of 3 dB across the frequency range. While the attenuator is designed and fabricated for full 2.4 mm coaxial band applications, the attenuation value of this model will have a wide range due to its broadband coverage. Various attenuation values are available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 24$335.00
25 - 49$301.50
50 +$271.35

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum FrequencyDC
Maximum Frequency50 GHz
Attenuation3 dB
Return Loss17 dB
Power Handling2 W
Connector 12.4 mm Male
Connector 22.4 mm Female
