SMA Coaxial Bandpass Filter

29.3 to 30.3 GHz, 60 dB Rejection
SKU:SCF-30301360-KFKF-B3
Availability:6 to 8 Weeks ARO
SCF-30301360-KFKF-B3 is a coaxial bandpass filter with a passband frequency of 29.3 to 30.3 GHz. The typical insertion loss of the bandpass filter is 3 dB and the passband ripple is ±0.5 dB. The rejection frequencies are 28 GHz or less and 31.5 GHz or higher. The typical rejection is 60 dB and the typical passband return loss of the filter is 11 dB. The RF connectors of the the filter are 2.92 mm Female connectors. Other configurations are available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,450.00
5 - 9$1,305.00
10 - 24$1,174.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband Frequency29.3 GHz
Maximum Passband Frequency30.3 GHz
Low Side Rejection60 dB
High Side Rejection60 dB
Return Loss11 dB
Insertion Loss3 dB
Impedance50 Ohms
RF PortsSMA (F)
