2.92 mm Coaxial Bandpass Filter

28 to 40 GHz, 40 dB Rejection
SKU:SCF-34312340-KFKF-B3
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCF-34312340-KFKF-B3 is a coaxial bandpass filter with a passband frequency of 28.0 to 40.0 GHz. The typical insertion loss of the bandpass filter is 3 dB and the passband ripple is ±0.75 dB. The rejection frequencies are 27.5 GHz or less and 43 GHz to 52.5 GHz. The typical rejection is 40 dB and the typical passband return loss of the filter is 14 dB. The RF connectors of the filter are 2.92 mm female connectors. Other configurations are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,450.00
5 - 9 $1,305.00
10 - 24 $1,174.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Passband Frequency28 GHz
Maximum Passband Frequency40 GHz
Low Side Rejection40 dB
High Side Rejection40 dB
Return Loss14 dB
Insertion Loss3 dB
Impedance50 Ohms
RF Ports2.92 mm (F)
