X3 Active Frequency Multiplier with Uni-Guide™

28 to 32 GHz, +18 dBm Output Power, In-line WR-28 Waveguide, Ka-Band
SFA-283323318-28SF-E1 is an active X3 frequency multiplier. The multiplier triples the input signal of 9.33 to 10.66 GHz at +10 dBm to yield an output signal of 28.0 to 32.0 GHz at +18 dBm. The harmonic suppression of the mulitiplier is -20 dBc typical. The DC power requirement for the multiplier is +8 VDC at 350 mA. The input port of this model is a female SMA connector and the output port is a WR-28 Uni-Guide™ waveguide with a UG-599/U flange. It is an in-line angle configuration. Other port configurations, such as right angle, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency28 GHz
Maximum Output Frequency32 GHz
Output Power+18 dBm
Minimum Input Frequency9.33 GHz
Maximum Input Frequency10.66 GHz
Input Power+10 dBm
DC Bias+8 VDC/350 mA
Output PortWR-28 Uni-Guide™ WG
Input PortSMA (F)
