Ka-Band Beam Switchable Receiver Assembly

27 to 29 GHz, 64 Channels
SSR-2830233605-28-S1 is a Ka Band receiver with four 16, total 64 channels receive paths. The receiver can be operated at the frequency range 27 to 29 GHz. Each 16 channel receiver path utilizes an SP16T with 100 ns switching speed and 50 dB isolation for 360° coverage in the horizontal plane and 90° coverage in the vertical plane. The receiver can be paired with the SST-2830231719-28-S1 for 5G and object detection etc. applications.
Login to view pricing

Technical Details

SpecificationsRF Frequency Range: 27 to 29 GHz
Antenna 3 dB Beamwidth: 45°
Antenna Gain: 11 dBi
Antenna Polarization: Linear
Receiver Gain: 5 dB
Receiver Noise Figure: 3.6 dB
Switch Speed: 100 ns
System Gain: 16 dB
RF Input Port (64X): WR-28 Waveguide
RF Output Port (4X): 2.92 mm (F) Connector
