Ka-Band Down-Converter

26 to 40 GHz RF Input, 10 MHz to 12 GHz IF Output, WR-28 Waveguide
SKU:STC-N10-28-S1
Availability:Contact Us for Quote
STC-N10-28-S1 is a Ka-Band down-converter that converts millimeter wave signals from a frequency range of 26 to 40 GHz to the baseband at 1.6 GHz. The down-converter requires 6.5 to 10 GHz at +5 dBm input power as its LO. The down-converter has low harmonic levels and excellent gain flatness, making it a good candidate to extend low frequency test equipment for millimeter wave testing purposes.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency26 GHz
Maximum RF Frequency40 GHz
Minimum IF Frequency10 MHz
Maximum IF Frequency12 GHz
Minimum LO Frequency6.5 GHz
Maximum LO Frequency10 GHz
Power Supply100 VAC to 240 VAC
RF PortWR-28 Waveguide
