180 Degree Coaxial Hybrid Coupler

26 to 40 GHz, 2.92 mm (F) Input/Output Ports, 3 dB Coupling
SKU:SCZ-2634031218-KFKF-43
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCZ-2634031218-KFKF-43 is a coaxial 180-degree hybrid coupler that covers the frequency range of 26 to 40 GHz. The nominal coupling is 3 dB and the typical insertion loss is 3.0 dB. The typical isolation of the coupler is 12 dB. The RF connectors of the coupler are female 2.92 mm (K) connectors. The power handling of the coupler is 50 watts maximum. Other configurations, such as different connectors for input and output, are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency26 GHz
Maximum Frequency40 GHz
Insertion Loss3.0 dB
Coupling3 dB
Return Loss12 dB
Impedance50 Ohms
RF PortsK (F)
