2-Way Coaxial Power Splitter

26.5 to 40 GHz, 2.92 mm (F)
SKU:SCS-2734030916-KFKF-22
Availability:4 to 6 Weeks ARO
SCS-2734030916-KFKF-22 is a coaxial 2-way power splitter with a typical insertion loss of 0.9 dB at each output port and a typical isolation of 16 dB across the frequency range of 26.5 to 40 GHz. The power splitter has a nominal power handling of 20 W (CW) and a typical amplitude unbalance of ±0.4 dB. The return loss for all ports is 12 dB typical. The RF connectors of the power splitter are female 2.92 mm (K) connectors.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$650.00
10 - 24$585.00
25 +$526.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Ways2
Insertion Loss0.9 dB
Port Isolation16 dB
Return Loss12 dB
Impedance50 Ohms
RF ConnectorsK (F)
