Ka-Band Power Amplifier with Uni-Guide™

26.5 to 40 GHz, 45 dB Gain, +26 dBm P1dB, WR-28 Waveguide, 2.92 mm (F)
SKU:SBP-2734034526-28KF-E1
Availability:1 to 2 Weeks ARO
SBP-2734034526-28KF-E1 is a Ka band power amplifier with a typical small signal gain of 45 dB and a nominal P1dB of +26 dBm across the frequency range of 26.5 to 40 GHz. The DC power requirement for the amplifier is +8 VDC/1,100 mA. The mechanical configuration is an inline structure with WR-28 waveguide as its input port and K(F) connector as its output port. Other port configurations, such as K connectors and WR-28 waveguides for either the input or output port, are also available under different model numbers.
ECCN: 3A001.b.4.e.1
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 2$3,300.00
3 - 4$3,135.00
5 +$2,978.25

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Gain45 dB
P1dB+26 dBm
Psat+27 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+8 VDC/1100 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide/2.92 mm (F) Connector
