Ka-Band Power Amplifier with Uni-Guide™

26.5 to 40 GHz, 35 dB Gain, +26 dBm P1dB, In-line WR-28 Waveguide
SKU:SBP-2734033526-2828-E1
Availability:Contact Us for Quote
SBP-2734033526-2828-E1 is a Ka band power amplifier with a typical small signal gain of 35 dB and a nominal P1dB of +26 dBm across the frequency range of 26.5 to 40 GHz. The DC power requirement for the amplifier is +8 VDC/1,100 mA. The RF connectors are WR-28 Uni-Guide™ waveguides. Other port configurations, such as K connectors for either the input or output port, are also available under different model numbers. The power amplifier requires a heatsink.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Gain35 dB
P1dB+26 dBm
Psat+27 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Voltage+8 VDC
DC Bias1100 mA
RF Input/OutputWR-28 Uni-Guide™ Waveguide
ConfigurationStandard
