X4 Active Frequency Multiplier

26.5 to 40 GHz, +20 dBm Output Power, WR-28 Waveguide, Ka-Band
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SFA-284SF-S1 is an active X4 frequency multiplier. The multiplier has an input frequency of 6.63 to 10 GHz with a typical input power of +5 dBm and an output frequency of 26.5 to 40 GHz with a typical output power of +20 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port configuration is a female SMA connector and the output is a WR-28 waveguide with a UG-599/U flange. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $3,250.00
3 - 4 $3,087.50
5 - 9 $2,933.13

Bulk Availability

1 - 9In Stock

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency26.5 GHz
Maximum Output Frequency40 GHz
Output Power+20 dBm
Minimum Input Frequency6.63 GHz
Maximum Input Frequency10 GHz
Input Power+5 dBm
DC Bias+8 VDC/300 mA
Output PortWR-28 WG
Input PortSMA (F)
