WR-75 Coaxial Rectangular Horn Antenna

25 dBi Gain, 9.84 to 15 GHz, N (F), Right Angle, X-Ku-Band
SKU:SAR-2510-75NF-R3
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-2510-75NF-R3 is a X-Ku-band pyramidal horn antenna with a right angle (90°) N type coax connector to cover the frequency range of 9.84 GHz to 15.0 GHz. The antenna offers 25 dBi nominal gain and a typical half power beamwidth of 9 degrees on the E-plane and 11 degrees on the H-plane. The antenna supports linear polarized waveforms.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency9.84 GHz
Maximum Frequency15 GHz
Gain25 dBi
3 dB Beamwidth, E-Plane
3 dB Beamwidth, H-Plane11°
Return Loss18 dB
Antenna Port90° N Female
