WR-10 Waveguide Conical Horn Antenna

25 dBi Gain, 87 to 100 GHz, W-Band
SKU:SAC-2507-10-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAC-2507-10-S2 is a W-band conical horn antenna that operates from 87 to 100 GHz. The antenna offers 25 dB nominal gain and a typical half powerbeam width of 9 degrees on the E-plane and 10 degrees on the H-plane. The horn also offers typical sidelobes of -18 dB on the E-plane and -28 dB on the H-plane. The conical horn can support linear polarization. The input of this antenna is a WR-10 waveguide with UG-387/U-M flange.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$720.00
10 - 24$648.00
25 +$583.20

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency87 GHz
Maximum Frequency100 GHz
Gain25 dBi
3 dB Beamwidth, E-Plane9°
3 dB Beamwidth, H-Plane10°
Return Loss23 dB
PolarizationLinear
Antenna PortWR-10 Waveguide
