Broadband Low Noise Amplifier

24 to 42 GHz, 30 dB Gain, 3.5 dB Noise Figure, 2.92 mm (F)
SKU:SBL-2434233035-KFKF-S1
Availability:3 to 5 Days ARO
SBL-2434233035-KFKF-S1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 3.5 dB across the frequency range of 24 to 42 GHz. The DC power requirement for the amplifier is +8 VDC/550 mA. The RF connectors are female K connectors. Other port configurations are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency24 GHz
Maximum Frequency42 GHz
Gain30 dB
Noise Figure3.5 dB
P1dB+20 dBm
Input Return Loss5 dB
Output Return Loss10 dB
DC Bias+8 VDC/550 mA
RF Input/Output2.92 mm (F)
