X4 Active Frequency Multiplier with Uni-Guide™

24 to 42 GHz, +16 dBm Output Power, In-line WR-28 Waveguide, Ka-Band
SFA-243423416-28SF-E1 is an active X4 frequency multiplier. The multiplier has an input frequency of 6 to 10.5 GHz with a typical input power of +5 dBm and an output frequency of 24 to 42 GHz with a typical output power of +16 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/300 mA. The input port of this model is a female SMA connector and the output port is a WR-28 Uni-Guide™ waveguide with a UG-599/U flange. It is an in-line angle configuration. Other port configurations, such as right angle, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $3,200.00
3 - 4 $3,040.00
5 - 9 $2,888.00

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency24 GHz
Maximum Output Frequency42 GHz
Output Power+16 dBm
Minimum Input Frequency6 GHz
Maximum Input Frequency10.5 GHz
Input Power+5 dBm
DC Bias+8 VDC/300 mA
Output PortWR-28 Uni-Guide™ WG
Input PortSMA (F)
